Electrosurgical Unit

  • Model: RES-120
  • Units in Stock: 9

$1,885.00

Feature:

  • Automatic control output, guarantee surgery quality
  • When turn on the Generator, it can check the system by itself
  • Five kind of working model: Pure cutting, blend, Concreting, fulgerize, Bipolar
    Memory function with 10 memory places for different setting: easy and fast set up
  • This ESU can give alarm when the patient plate do not connect properly
  • The 1000KHZ radio-frequency frequency, reduces the organization to damage
  • There are three kinds of sound to show the 4 different working modes as the following: Error Warning; Cutting & Coagulation; Bipolar
  • Provides the high efficiency smoke absorber, protects the medical care personnel
  • Classification: Class I, Type BF
  • Quality Management:ISO13485
  • Line Voltage:220V/110V 50/60Hz
  • Power consumption:360VA(max.)

Application:

  • gynecologic-LEEP, the five sense organs and neurosurgery, ENT, and cosmetology

Specification:



Work Mode

Frequency

Power

Form of RF current

Vp-p

Monopole

Pure Cut

1.00MHz

0-120W(300Ω)

Sine Wave

1100V

Blend 1

1.00MHz

0-100W(300Ω)

Modulate Sine Wave

1500V

Blend 2

1.00MHz

0-90W(300Ω)

Modulate Sine Wave

1900V

Coagulation

1.00MHz

0-70W(300Ω)

Modulate Sine Wave

3060V

Fulgurate

1.00MHz

0-60W(300Ω)

Modulate Sine Wave

4120V

Bipolar

Bipolar Coagulation

1.00MHz

0-60W(100Ω)

Sine Wave

1000V






Add to Cart:



This product was added to our catalog on Friday 30 March, 2012.
